Yamato SM Series Standard Autoclaves & Steam Sterilizers with Dryer

Overview

Yamato SM Series Standard Autoclaves & Steam Sterilizers with Dryer (models SM201/SM211/SM301/SM311/SM501/SM511) are automatic high pressure steam sterilization systems equipped with integrated dryer technology for quick sample drying. Sterilization operating temperature ranges are SM201/SM211: 105 to 1230C; SM301/SM311: 105 to 1280C; SM501/SM511: 105 to 1280C, with drying operating temperature 150 to 1800C and maximum pressure capacity SM201/SM211: 0.18MPa; SM301/SM311/SM501/SM511: 0.2MPa. The interior is stainless steel and sterilization heater power is SM201/SM211: 1.3kW; SM301/SM311: 1.7kW; SM501: 1.7kW; SM511: 2.0kW, while drying heater power is SM201/SM211: 1.0kW; SM301/SM311/SM501/SM511: 1.5kW. Temperature is PID controlled by microprocessor with a green LED digital display and ▲▼ keys, timer range 1 min. ~ 99 hrs. and 59 min. and 100~ 999 hrs. with resolution 1 min. or 1 hr., and safety devices include self-diagnostic functions (detection sensor error, SSR short circuit, heater disconnect, faulty main relay, dry operation), safety valve, electric leakage breaker, and drain bottle set-fail switch. Internal dimensions are SM201/SM211: ⌀240 x D445 mm; SM301/SM311: ⌀300 x D445 mm; SM501/SM511: ⌀300 x D665 mm, external dimensions WxDxH are SM201/SM211: 410 x 470 x 957 mm; SM301/SM311: 440 x 530 x 968 mm; SM501/SM511: 440 x 530 x 1088 mm, internal capacities are SM201/SM211: 20L; SM301/SM311: 32L; SM501/SM511: 47L, and weights are SM201/SM211: ~65kg; SM301/SM311: ~80kg; SM501/SM511: ~85kg. Included accessories per model are SM201/SM211: 2 pcs. stainless steel mesh basket (⌀209 x D204 mm); SM301/SM311: 2 pcs. stainless steel mesh basket (⌀266 x D204 mm); SM501/SM511: 2 pcs. stainless steel mesh basket (⌀266 x D315 mm), with additional included items drain board, drain bottle, and condensation collection container with magnetic bracket; listed prices are SM201/SM211: $ 7,885; SM301/SM311: $ 8,350; SM501/SM511: $ 9,275. Power source (50/60Hz single phase) specifications are SM201/SM211: AC115V 13A (with plug) / AC220V 7A (no plug, round terminal); SM301/SM311/SM501/SM511: AC115V 15A (no plug, round terminal) / AC220V 9.5A (no plug, round terminal). The SM series is described for disinfecting lab, medical, or dental equipment and for sterilizing tubing of mechanical ventilators. The product information highlights use for sterilizing respiratory therapy equipment in hospitals and for small medical instruments such as syringes, needles, cannulas, and forceps, noting non-plastic items may be exposed to temperatures up to 135 0C. Dental instrument sterilization is referenced with recommended exposure between 134 0C-137 0C at a 2.1-2.25 bar gauge pressure for a holding time of 3 minutes, and laboratory research applications are listed for disinfecting liquid samples and solid apparatus in pharmaceutical, life science, food safety, and water based lubricant and coolant industries.
