PMC-1250 Gravity Die Casting Machine

Overview

The PMC-1250 Gravity Die Casting Machine features 1250 × 1100 mm tie-bar spacing, die platen dimension 1580 x 1565 mm, die height distance 400 ~ 900 mm, die stroke 1000 mm, and tie bar diameter Ø 110 mm. Clamping force is 80 ton and ejecting force is 12 ton. Ejecting strokes are mid ejection stroke 0~200 mm and front ejection stroke 0~150 mm. Motor capacity is 58 KVA and machine size is 5650L x 2500W x 5650H with machine weight 21 ton. The control platform is available in PNC or computer-based modes and supports fully automated control of tilt angle, motion sequence, and mold operation. It is equipped with a servo energy-saving motor system replacing conventional motors to reduce energy consumption and mechanical wear while improving operational stability and precision. Designed for large aluminum gravity and permanent mold casting, the PMC-1250 delivers high stability, precision, and improved production efficiency. It enables stable control of metal flow, filling behavior, and solidification to improve casting density, reduce porosity, and enhance surface quality. The PMC-1250 is designed for large aluminum gravity and permanent mold casting. It is especially suitable for automotive structural components, industrial equipment, and large mold applications, meeting the demand for high-quality casting production.
