MU-8000V

Overview

The MU-8000V is a 5-axis vertical machining center with a highly rigid double-column structure and a trunnion table that provides a low center of gravity in workpiece movement. Its high-speed, high-accuracy trunnion table enables fast, accurate positioning for simultaneous 5-axis cutting and supports both heavy-duty cutting and high-speed finishing. The machine is built on Okuma’s Thermo-Friendly structure to perform consistently from the first part to the last regardless of warm-up time or ambient temperature. The MU-8000V uses Okuma OSP-P500 control (Specifications shown are for OSP-P500 configuration) and can be adapted for APC, multiple ATC, automation, or FMS with expansion at the back of the machine. Highlighted Specs (as provided): Max Machining Volume (in): d839.37 x 21.65 Table Size (in): d824.80 Spindle Speed (minb9): 10,000 [15K, 20K, 25K] Spindle Motor Power (hp): 22/18.5 Rapid Traverse (ipm): 1,969 Magazine Capacity: 32 [48, 64] Max Machining Volume (mm): d81000 x 550 Table Size (mm): d8800 Spindle Motor Power (kW): 11/7.5 Rapid Traverse (m/min): 50 The MU-8000V is presented for high-efficiency, high-productivity 5-axis, multi-sided machining. It is described as supporting both heavy-duty cutting and high-speed finishing while enabling simultaneous 5-axis cutting through fast, accurate table positioning. The machine can be adapted for use with APC, multiple ATC, automation, or FMS, and is described as automation-friendly.
