MY-500 High speed wire EDM cut machine

Overview

MY-500 High speed wire EDM cut machine is a high-precision servo wire cut EDM machine tool with a C-shaped structure design that the manufacturer states is stable and long-lived. The machine’s cut speed is 15 % higher than that of other brands, and its cut accuracy and roughness are described as at the leading level in the industry. Key workspace and cutting specifications include a worktable size of 720*530 mm, CNC axis travel (X*Y) 500*400 mm, U/V travel 32 mm, Z travel 250 mm, max. cutting workpiece thickness 280 mm, max cutting taper ±6°/80mm, and max workpiece weight 500 kg. The molybdenum wire diameter is φ0.18 mm. Performance and utility figures list cutting accuracy ≤±0.005∠20mm H=30mm(multiple cutting), surface roughness Ra≤0.65 μm, cutting efficiency 8000~15000 mm2/hr, and power consumption ≤3Kw 2-phase 220V. Machine dimensions are 1900*1300*1950 mm, cabinet size 850*680*1760 mm, tank size 1030*660*860 mm, and machine weight ≤1800 kg. Drive and control details include Motor Controller: XY servo motor UV stepper motor; Z axis lift type: Auto-lift; X/Y axis type: Auto-manual; controlled axis: 4-axises; lead screw/guide type: Ball screw/Linear guide (made in Taiwan/ Germany); control system: Autocut. Additional equipment and capacities: Tanker 150 L, filter type 3nd filtration, min. moving unit 0.001 mm, molybdenum wire tensioning device √, table waterproof cover √, DRO √, Aluminum Cutting Device √. The MY-500 is presented as a high-precision wire cut EDM machine tool for wire EDM cutting operations, emphasizing higher cut speed and leading cut accuracy and surface roughness. It is configured to perform multiple cutting as indicated in the cutting accuracy specification (H=30mm(multiple cutting)). The machine supports cutting workpieces up to 280 mm thick and up to 500 kg in weight, and includes an Aluminum Cutting Device as part of its equipment set.
