L-3018

Overview

The L-3018 is a water-only waterjet described as "Ultra Fast, Ultra Precise". It delivers the same cutting speed as the L-3025 while offering a slightly reduced cutting envelope and footprint. The machine can accommodate multiple cutting heads or 5-Axis cutting heads on the same cross beam. Footprint: 37.7' x 12.3' (11.48 m x 3.76 m). One Carriage X-Y Cutting Area: 120" x 72" (3.05 m x 1.83 m). Z-Axis Travel: 12" (0.30 m). Software: IKUHLU, WARDCAM. Power Requirements (Gantry Only): 460V 30 amps, Three Phase. Air Requirements: 80 psi, 2 cfm (5.52 bar, 0.06 cmm). Max Number of Z-Carriages: 4. Bulk Feed Hopper: N/A. Drive Mechanism: Linear Drive. Linear Positional Accuracy: ± 0.003" per axis (± 0.08 mm per axis). Repeatability: ± 0.001" per axis (± 0.03 mm per axis). Speed: 0.01 in/min - 7000 in/min (0.25 mm/min - 178 m/min). The L-3018 supports multiple cutting heads or 5-Axis cutting heads on the same cross beam. It can be equipped with optical eyes, guillotine doors, and chain-fed loading tables to create a fully automated system.
