SERIES 11 Ceiling Mount Unit

Overview

The SERIES 11 Ceiling Mount Unit is offered in 1-5 Ton units and is a compact ceiling-mounted product designed for quiet, reliable and efficient environment control; it allows for efficient use of space and provides effective, high sensible cooling for equipment cooling applications. Cooling modes available for 1-5 Ton Units include Air Cooled DX, Water Cooled DX, and Glycol Cooled DX (DX in R407C or R410A); Chilled Water is available for 4-5 Ton Units, and Dual Cool and Free Cool modes are offered. Reheat options include 5kW (1-3 Ton), 6kW (3-5 Ton), Hot Water (4-5 Ton Units) and Hot Gas (4-5 Ton Units). Configurations offered include Packaged Air Cooled (1-2.5 Ton), Remote Condensing Units (1-2.5 Ton Only), Remote Condensers, Grille Supply and Return (1-3 Ton), Ducted, and Split System. Three levels of control are available: an advanced microprocessor precision control system with large touch screen graphic LCD display and multi-functional Co-WorkTM control (network ready for up to eight units; includes PID control, alarm and event log, graphic trending of temperature and humidity, continuous room and unit status display), the ClimateWorx-Siebe Network Controller for cooling-only network applications, and a single unit thermostat. The indoor unit housing is constructed of heavy gauge steel with durable epoxy powder paint and hinged panels for full service access, and the refrigeration system features a high EER scroll compressor and high efficiency slab cooling coil available for operation on non-ozone depleting R407C unless specified otherwise. Optional accessories include a 1KW tubular finned electric reheat and a 5 lb/hr electrode boiler steam humidifier with automatic water level control and auto adaptive control for operation on ordinary tap water. All ClimateWorx equipment is evaluated and accepted by a Nationally Recognized Testing Laboratory (NRTL) to UL 1995 standard and the company holds ISO 9001:2015. The Series 11 is described as providing effective, high sensible cooling for equipment cooling applications. It is specifically designed for remote mobile telecommunication shelters, cellular sites, data switch rooms, projection rooms, and hi-tech offices. The ClimateWorx-Siebe Network Controller option is described as designed for cooling-only network applications and is ideally suited for remote telecom shelters.
