DDA 200-4 AR-PV/V/C-F-31A7A7BG

Overview

Electronic metering/dosing pump with a PVDF (Polyvinylidene fluoride) dosing head, ceramic valve ball and FKM gaskets. Flow capacity ranges from 250 ml/h (minimum) up to 52.83 US gal/hour (maximum) with a turn-down ratio of 1:800 and an accuracy of repeatability of 1.5%. Maximum operating pressure is 58.02 psi. Viscosity handling: maximum 100 mPas at 100 % output; in slow mode 50 % the maximum viscosity is 1000 mPas (max flow 26.42 US gal/hour) and in slow mode 25 % the maximum viscosity is 2000 mPas (max flow 13.21 US gal/hour). Maximum suction lift during priming is 4.92 ft and during operation 9.84 ft. Liquid temperature range 32 .. 122 °F; selected liquid temperature shown as 68 °F. Designed for precise automated dosing of water and media compatible with PVDF, ceramic and FKM wetted parts, suitable for industrial and potable-water-related applications (approvals: CE, CSA-US, NSF61, RCM). Control and integration features include a front-mounted control panel, control variant AR, analog input and analog output 0/4-20 mA, pulse control, external Stop input, level control, bus communication and 2 output relays — enabling PLC/SCADA integration and tank-level interlocks. Electrical and installation constraints to consider during system design: rated voltage 1 x 100-240 V, main frequency 50 / 60 Hz, inrush current 70A at 240V (35A/100V) for 2ms, maximum power input P1 62 W; enclosure class IP65 / TYPE 4X; pump inlet/outlet Conn. Threaded 3/4#NPTM CodeA7; net weight 15.4 lb and cable length 4.92 ft. Operational envelope (ambient 32 .. 113 °F, liquid 32 .. 122 °F), suction lift and max pressure (58.02 psi) should be used to place the pump and specify upstream/downstream pipework and suction conditions.
