Quiet Enclosed Reciprocating Air Compressor, 5-15 HP

Overview

The Ingersoll Rand Quiet Enclosed Reciprocating Air Compressor, 5-15 HP combines some of the lowest dBA levels in the industry (as low as 65 dBA) with reliability, efficiency and productivity. The range covers 5-15 HP (4-11kW) and is offered as quiet enclosed reciprocating compressors intended to lower costs and speed up return on investment. It features a Type 30 base built with enclosure and a floating sub-base design for noise and vibration control; an overhung crankshaft, weather resistant powder-coat finish and a durable cast iron pump for 100% continuous duty application; a two-stage pump operating up to 175 psi with 80-120 gallon ASME receiver tanks; All Season Select synthetic lubricant with 2,000 hours between change outs (performs four times longer than petroleum-based lubricants); and two-stage filtering that includes an inlet filter and a pad pre-filter. Model 2475QD5: Nominal Power 5 hp, CFM @ 90 psi 17.2, Flow at Max Pressure 16.8 cfm, Max Pressure 175 psig, Tank 80 gal, NPT Outlet 0.5 in, Base Length 70.5 in x Width 33.3 in x Height 65.2 in, Weight 1246 lbs, Noise Level Standard Pressure 66 dBA. Model 2475QD7.5: Nominal Power 7.5 hp, CFM @ 90 psi 24.3, Flow at Max Pressure 24 cfm, Max Pressure 175 psig, Tank 80 gal, NPT Outlet 0.5 in, Base Length 70.5 in x Width 33.3 in x Height 65.2 in, Weight 1286 lbs, Noise Level Standard Pressure 68 dBA. Model 2545QE10: Nominal Power 10 hp, CFM @ 90 psi 35.6, Flow at Max Pressure 35 cfm, Max Pressure 175 psig, Tank 120 gal, NPT Outlet 0.75 in, Base Length 75.6 in x Width 34.3 in x Height 74 in, Weight 1439 lbs, Noise Level Standard Pressure 65 dBA. Model 7100QE15: Nominal Power 15 hp, CFM @ 90 psi 51, Flow at Max Pressure 50 cfm, Max Pressure 175 psig, Tank 120 gal, NPT Outlet 0.75 in, Base Length 75.6 in x Width 34.3 in x Height 74 in, Weight 1776 lbs, Noise Level Standard Pressure 67 dBA. The compressors are specified for 100% continuous duty application and provide uninterrupted supply of clean air through two-stage filtering and a two-stage pump operating up to 175 psig. The 80-120 gallon ASME receiver tanks combined with model flow ratings (CFM @ 90 psi and Flow at Max Pressure) are presented as providing "plenty of punch for the most demanding applications." Noise and vibration control features — Type 30 base with enclosure, floating sub-base design, and measured noise levels as low as 65 dBA — are included as part of the product's operational characteristics.
