Multi-Purpose U shape Vibratory - VBU-C-L Series

Overview

Multi-Purpose U shape Vibratory - VBU-C-L Series features a U shaped working bowl with a high efficiency motor and high class springs that enhance processing efficiency 30% higher than traditional machine. The inner barrel is coated with PU lining to resist acid, alkaline, abrasion and to eliminate the impingement of collision. The machine is equipped with an Automatic Lift System for quick and easy removal or installation of polish parts, and the robust structured barrel with independent Automatic Lift System design provides higher processing efficiency and operational stability. Additional systems include an Automatic Compound Supply System for precise control of polish liquid usage, a variable shift and speed control system, an Automatic Lubricant Supply System to control lubricant input flow and protect the motor, a special fixture design to eliminate impingement of collision during operation, and a base with a shockproof stand to enhance operational stability. Model VBU-C-L 1500 dimensions: A 2318 mm, B 1450 mm, C 540 mm, D 608 mm, E 1270 mm, F 2570 mm, G 3070 mm, ST 500 mm. Capacity and handling data: Capacity 1500L, Filling 3000 kg, Motor 15 kw, Amplitude 2~7 mm. Weight and packing: Weight 2456 kg, Packing Dimension 2470x2470x1650 mm, G.W. 2910 KGS, Volume 331.18'. Application: Suits for polishing various material such as Steel, Stainless Steel, Aluminum, Brass, Zinc...etc.
