Horizontal mitre band saw BS-260G

Overview

Model BS-260G. Warranty: 1 year on equipment. Availability: In stock. Delivery to RF and CIS countries. The seller states operation/support 24/7. Cutting capacities (as specified): - At 90°: round 227mm (9”), rectangular 260×200mm (10”x7.9”); - At 60°: round 90mm (3.5”), rectangular 85×85mm (3.5”x3.5”); - At 45°: round 150mm (6”), rectangular 150×125mm (6”x5”). Blade and drive parameters: blade size 20X0.9X2445mm. Blade speed @50Hz: 2P, 72m/min 236FPM; 4P, 36m/min 118FPM. Blade speed @60Hz: 2P, 86m/min 283FPM; 4P, 43m/min 141FPM. Motor power listed as 0.75/1.1kW and 1/1.5Л.с. (3 phases). Drive type: gear drive. Packing dimensions: 145x72x102 cm. Net/Gross weight: 220/275kg. Equipment features explicitly listed: cast saw frame with maximum tilt angle 60°; hydraulic descent; fast-acting lever for locking/unlocking the swivel head; cooling system included as standard; control panel installed for easy access; adjustable length stop for multiple cuts. The machine is specified for cutting stock at set angles: it supports 90°, 60° and 45° cutting with the documented round and rectangular section capacities. The adjustable length stop is provided for repeated/multiple cutting operations. The cast frame with up to 60° tilt, the swivel head locking/unlocking lever and hydraulic descent are presented as features supporting angled cutting operations, and a cooling system is included in the standard configuration.
