GrindPro Series - Metal Grinding Booth

Overview

GrindPro Series - Metal Grinding Booth is a fully enclosed, high-performance unit specifically designed for use with air tools and provides a self-contained environment with complete dust extraction and automatic filter cleaning. The booth features a large view window of durable safety glass with an easy-change splash shield, dual safety doors with safety interlocks, foot-pedal control and smart automation via a PLC interface with auto start/stop, timer and system diagnostics. A high-rate ventilator provides powerful extraction with automatic, adjustable filter cleaning and the extraction system shuts off when idle to save power. Technical specifications: - External Machine Dimensions (L x W x H) in mm/inch: 1285 x 1520 x 2106 / 51 x 60 x 83 - Grinding Room Dimensions (L x W x H) in mm/inch: 1170 x 940 x 885 / 46 x 37 x 35 - Working Height in mm / inch: 800 / 31.5 - Door Openings (W x H) in mm/inch: 835 x 725 / 33 x 28.5 - View Window (W x H) in mm/inch: 656 x 266 / 26 x 10.5 - Maximum Load in Kg.: 500 - Dust Emission: < 1,8 mg/ Nm³ - Electrical Connection: 3 x 400V, 50 Hz, earth and zero - Total Power Consumption in kW: 1,2 The GrindPro Precision Metal Grinding Booth is described for manual grinding and deburring operations. It is also specified for air tool finishing. The booth is intended for surface preparation before coating or welding.
