Photovoltaic - Laser Edge Cleaning

Overview

The Photovoltaic Laser Edge Cleaning system delivers precision edge removal for battery cell electrodes through advanced laser technology and high-speed galvanometric scanning capabilities. ## Key Features - Dual-pass cleaning mechanism for front and back polarity edges, effectively preventing cross-contamination and mutual melting - Compatible with battery cells ranging from 100-300mm in width for versatile production requirements - Ultra-precise stage horizontal accuracy of ≤4μm with CCD positioning accuracy of ≤0.01mm - Minimal heat affected zone of ≤10μm, preserving critical cell properties during processing - Residue-free operation verified by microscopic inspection, ensuring clean edge definition - High-precision splicing accuracy of ≤0.01mm at edge clearing interfaces for seamless results - Film thickness processing capability of ≤2μm for handling delicate electrode materials ## Key Technical Specifications |||| |:--|:--|:--| |**Film Thickness**|≤2μm|| |**Stage Horizontal Accuracy**|≤4μm|| |**Heat Affected Zone**|≤10-15μm|| |**CCD Positioning Accuracy**|≤0.01mm|| |**Edge Cleaning Positioning Accuracy**|≤0.02mm|| |**Splicing Accuracy**|≤0.01mm|| |**Residue After Cleaning**|None|| ## Compatibility and Standards - **Electrical Certification:** GB. Optional conversion of this equipment to UL/CE standards - contact Diagon for details - **Control Systems:** Standard Omron series. Optional control system migration (Siemens, Rockwell/Allen-Bradley, others) to match your existing infrastructure - contact Diagon for compatibility assessment Serial Number: 42-90542
