BROCKHAUS WAF-1.200

Overview

BROCKHAUS WAF-1.200 is an activated carbon filter with a quick-change system (SWS) designed for water applications. By using different types of activated carbon, VOCs, H₂S, NH₃, and Hg can be reliably adsorbed. The internal, electrically conductive two-component coating provides additional protection against corrosion and prevents electrostatic charging, increasing operational safety. Integrated sampling points allow for easy monitoring of filter performance. Type: SWS-Air Activated Carbon Filter 1,200. Operating pressure: min. -1 bar / max. 6 bar. Operating temperature: min. -10 °C / max. 80 °C. Flow rate: 2 -5 m³/h. Fluid group: 1. Filter volume: approx. 1.2 m³. Empty weight: approx. 1.200 kg. Operating weight: 3,000 kg. Dimensions (LxWxH): 1.5 m x 1.5 m x 2.4 m. Diameter: 1.2 m. Filter material: S235 with electrically conductive 2K inner coating. Piping: 1.4571 or HDPE. Valves: TA-Air compliant. Connections: Flange connections (DIN EN 1092-1). The WAF-1.200 is intended for water applications where adsorption of VOCs, H₂S, NH₃, and Hg is required by selecting suitable activated carbon types. As a full-service option, the unit can be adapted to specific applications and equipped with additional components such as additional filter units, hoses, condensate separators, safety equipment, measuring instruments, and control systems to provide a complete, safe, and autonomous solution.
