MPJ Series

Overview

MPJ Series is a Flexible Double Column Machine (Double Column Type Machining Center). Distance Between Column inch(mm): 102.4/122.0/141.7 (2600/3100/3600). Height inch(mm): 72.83 (1850). X Stroke inch(mm): 165.3/204.7/244.1 (4200/5200/6200). Y Stroke inch(mm): 118.1/137.8/157.5 (3000/3500/4000). Z Stroke inch(mm): 31.5 (800). W Stroke inch(mm): 39.4 (1000). TABLE size inch(mm): 78.7 x 157.4 ~ 122.0 x 236.2 (2000 x 4000 ~ 3100 x 6000). Max. load lbs(kg): 44000 ~ 72750 (20000 ~ 33000). ATC Tool Pod: 60. Control: FANUC. Spindle (RPM): 4000. RAM-type Spindle Head (Attachment change capable): the thick, 14.96\u201d-square (380mm-square) ram is hardened and ground with high accuracy on straightness, squareness and parallelism. 393 ipm (10,000 mm/min) X, Y and Z-axes Feed Rate. Standard 5-face cutter head is designed and manufactured for AATC, AAI compatible. Optional items listed include Automatic Attachment Changer (AAC), Automatic Attachment Tool Changer (AATC), Automatic attachment indexing device (AAI - 5deg.), Direct Table Change type Automatic Workpiece Changer (DTC/AWC), and Angle head and Snout (Optional). The MPJ Series Flexible Double Column Machine is generally used for 5-sided machining applications of precision industrial parts. Optional functions described in the product information include AAC (Automatic Attachment Changer) and AATC (Automatic Attachment Tool Changer), each described as providing higher productivity, an Automatic attachment indexing device (AAI) for automatic indexing at every 5 degree, and DTC/AWC which allows the table to directly ride on the machine bed to increase machine rigidity and accuracy.
